Mediator PCI 3000D 3V  MK-IV
  • Mediator PCI 3000D 3V  MK-IV

Mediator PCI 3000D 3V MK-IV


Busboard with five PCI and six ZIII slots for towerised Amiga 3000D.

Last items in stock

Busboard with five PCI and six ZIII slots for towerised Amiga 3000D.

The Mediator PCI 3000 D busboard is designed to enable expansion of towerised Amiga 4000D with a wide range of high-performance, low-cost PCI cards.

- 5 PCI slots (PCI 2.1 compatible)
- 6 Zorro III/II slots and one video slot
- 66/33MHz PCI clock (transfer rate up to 264MB/s)
- 32-bit PCI datapath
- 4GB PCI memory space
- Busmastering/DMA in all PCI slots
- SDRAM/SGRAM of PCI gfx card as a fast DMA buffer
- DMA to A3000 motherboard space
- Address and data parity control support
- Interrupt controller (4 lines to each PCI card)
- Compatibility with all A3000 processor card models
- Simultaneous operation of up to five PCI and up to six Zorro III/II cards

- 2D graphic drivers for: Radeon 9200, Voodoo5, Voodoo4, Voodoo3, Voodoo Banshee,
- S3 Virge and S3 Virge DX PCI graphic cards
- Warp 3D drivers working with Voodoo5, Voodoo4 and Voodoo3 graphic cards
- TV tuner drivers for: most of available PCI TV tuners (over 100 models supported)
- AHI sound drivers for: Sound Blaster 4.1 Digital, Sound Blaster 128 and
- ForteMedia FM801-based sound cards (e.g. Terratec 512i Digital)
- USB drivers for the Poseidon stack for: Spider and Spider II USB 2.0 cards
- Network Sana-2 drivers for: Fast Ethernet 100Mbps PCI cards
- Network Sana-2 drivers for: Ethernet 10Mbps PCI cards

Current info about supported PCI cards is available in the Mediator Driver Guide.

Package contents:
- Mediator PCI 4000 Core Logic card
- Elbox A3000 7xZIII / 5xPCI busboard
- Mediator PCI 3000D busboard
- 5 spacers with bolts
- Mediator Multimedia CD
- User's Manual

This product is covered by 2-year warranty and free Elbox Technical Support.

For more info about this product see Mediator PCI 3000D page at
